DABLJ

Bar Linear Grille w/ Mud-In Flange

Dayus DABLJ Bar Linear Grille Mud-In Flange Concealed Mud and Spackle
Dayus DABLJ Bar Linear Grille Mud-In Flange Concealed Mud and Spackle
 thumbnail
Dayus DABLJ Bar Linear Grille Mud-In Flange Concealed Mud and Spackle thumbnail
Dayus DABLJ Bar Linear Grille Mud-In Flange Concealed Mud and Spackle thumbnail

New Customers

Get a Quote

Returning Customers

Portal Quote & Order
3 day ship guarantee

The DABLJ is a fully extruded bar linear grille with a concealed, mud-in flange. Its customizable, fixed blades are parallel to the long dimension.

Features

  • Fixed blades are parallel to the long dimension unless specified otherwise
  • Recessed flange frame installs with tape and plaster for a concealed appearance
  • Select from six blade options
  • Fully extruded architectural aluminum construction
  • Available on 1/2" standard dimensions
  • Custom sizes manufactured up to 1/16" increments
  • Available in durable powder coat finish standard

Blade Options







-00 | 0° Deflection


-01 | 0° Deflection

-15 | 15° Deflection







-30 | 30° Deflection

-82 | 0° Air Flow

-84 | 0° Heel Proof (Narrow)

Finishes




W | White


S | Silver


M | Mill







B | Brown

FB | Flat

Black


Special

Order



W - White



S - Silver



M - Mill

Common Uses

The DABLJ is commonly used in ceiling or sidewall applications. It is not designed for floor use.

Mounting Options







-A | Screw Holes


-C | Concealed Brackets










-D | Sidewall Screws

(Removable Core Only)


-TB | No Mounting




Additional Options

DABLDJ | Opposed Blade Damper

DABLRJ | Removable Core

DABLH | Drywall-In Flange

DABLN | No Flange
